Product details

1.Aircooling, compact machine,output beam quality, high reliability, no consumables, maintenance-free.
2. Long life working. Import Germany IPG fiber laser, the international latest, most reliable structure, small
size, power consumption is small, no high-voltage without large water-cooled system
3.Close to the ideal beam, USB interface, output control, optical scanning system, laser repetition rate high, high-speed without distortion.

1.Adopt imported semiconductor module,high speed optical scanner, Q switch,providing speedy scanning and high precision.

2. it use semiconductor diode pump Nd: YAG crystals with a wavelength of 808nm, so that YAG rods generate a large number of reversal particles.

3.Under the function of Q switch, there will produce colossal pulse light beam output with a wavelength of 1064nm.

Parameter

Product name	fiber laser  marking machine
laser power	20W/30W/50w
Laser Length	1060mm
Quality of laser Beam	m2<1.5
Laser Repetition Frequency	≤100 KHz
Standard Marking Area	200*200mm
Engraving Depth	≤1.2mm
Engraving speed	≤12000mm/s
Minimum Line Width	0.01mm
Minimum Character	0.05mm
Resolution Ratio	±0.001mm
Gross Power	≤500W
Working Voltage	200V/50Hz/10A
Working area	110*110mm, 200*200mm
Software	EZCAD
Laser Type	Laser Type
Laser generator:	Raycus /MAX
Applicable Material	metal plastic ALL except glass
Warranty	3 years
Package size	80*30*80cm
Package weight	55 kg

---
